Overview

FRLSH Cables are insulated with a flame-retardant, low smoke, halogen-free compound that ensures high fire safety without compromising electrical performance. In the event of fire, these cables:

Key Features

  • Conductor: 99.97% pure, annealed copper (multi-stranded)
  • Insulation: Halogen-Free Flame-Retardant (HFFR) compound
  • Voltage Rating: 1100V
  • Operating Temperature: -15°C to +85°C
  • Conductor Class: Class 5 (Flexible) as per IS 8130
  • Smoke Density: Low, conforms to ASTM E 662
  • Halogen Emission: ≤ 0.5% (IEC 60754-1)
  • Flame Retardance: Passes IEC 60332-1 & IS 10810 standards
  • Toxicity Index: Low, compliant with international standards

Global Presence

  • Presence across major sectors, brands, and countries.
  • Transparency in all dealings.
  • World class manufacturing facilities.
  • Robust R&D Capabilities.
  • End-to-end solutions provider.
  • Visionary promoters & management.

Why Choose Us

  • Low Smoke Emission – Improves visibility and reduces suffocation during fire
  • Zero Halogen – Prevents release of toxic gases, minimizing corrosive damage
  • High Flame Retardance – Inhibits the spread of fire through wiring systems
  • Environmental Friendly – Lead-free and compliant with RoHS standards
  • Safe for Enclosed Spaces – Ideal for areas with limited ventilation or evacuation challenges
  • Long-Lasting Durability – Resistant to heat, moisture, oil, and chemicals

Applications

  • Commercial buildings and office complexes
  • Residential high-rises and housing societies
  • Airports, metros, tunnels, and underground stations
  • Hospitals, hotels, and public gathering spaces
  • Data centers, server rooms, and laboratories
  • Educational institutions, libraries, and museums
Parameter Value
Conductor Material Electrolytic Grade Annealed Copper (99.97%)
Insulation Halogen-Free Flame Retardant (HFFR) Compound
Voltage Rating 1100 Volts
Temperature Range -15°C to +85°C
Smoke Density < 60% (ASTM E 662)
Halogen Content ≤ 0.5% (IEC 60754-1)
Oxygen Index > 29% (IS 10810 Part 58)
Flame Test Compliance IEC 60332-1, IEC 60332-3
Available Sizes 0.5 sq.mm to 16 sq.mm (single/multi-core)
Packaging 90m/100m coils, custom drums available
