HRFR Cables
HRFR Cables
Overview
Our HRFR (Heat Resistant Flame Retardant) Cables are specially designed to deliver unmatched protection, flexibility, and longevity in the most demanding conditions. Whether you’re outfitting residential buildings, commercial complexes, or industrial facilities, these cables provide safe and efficient power distribution with enhanced flame resistance.
Key Features
- Conductor: 99.97% pure electrolytic grade, annealed copper
- Insulation: HRFR PVC (Lead-Free, Non-Toxic)
- Voltage Grade: Up to 1100 Volts
- Temperature Range: -15°C to +85°C
- Flame Retardancy: Complies with IS 694 and IEC 60332
- Insulation Resistance: > 1 Mega Ohm/km
- Available Sizes: 0.5 sq.mm to 16 sq.mm (custom sizes on request)
- Colors: Red, Yellow, Blue, Black, Green, White, Grey, and more
Global Presence
- Presence across major sectors, brands, and countries.
- Transparency in all dealings.
- World class manufacturing facilities.
- Robust R&D Capabilities.
- End-to-end solutions provider.
- Visionary promoters & management.
Why Choose Us
- High Thermal Endurance: Withstands elevated temperatures during overloads
- Flame Retardant: Reduces the risk of fire propagation
- Flexible & Easy to Install: Multistranded copper core for smooth handling
- Low Smoke Emission: Safer in enclosed areas during fire incidents
- Long Service Life: Resists moisture, chemicals, abrasion, and aging
- RoHS Compliant: Eco-friendly and lead-free formulation
Applications
- Internal wiring of residential & commercial buildings
- Power & lighting circuits
- Distribution boards and panels
- HVAC systems and fire alarm setups
- Industrial control equipment and appliances
| Parameter | Description |
|---|---|
| Conductor Material | Annealed Electrolytic Copper |
| Insulation Type | HRFR PVC Compound |
| Voltage Rating | 1100V AC |
| Temperature Range | -15°C to +85°C |
| Flame Retardancy Standard | IS 10810 / IEC 60332 |
| Insulation Resistance | > 1 MΩ/km at 27°C |
| Sizes Available | 0.5 sq.mm to 16 sq.mm |
| Conformance | IS 694:2010, CE, RoHS |
