Networking Cables (Cat 6)
Networking Cables (Cat 6)
Overview
Category 6 (Cat 6) cable is a twisted pair Ethernet cable used for networking and data transfer. It is backward compatible with Cat 5 and Cat 5e but offers improved performance and bandwidth, supporting frequencies up to 250 MHz and data transfer rates up to 1 Gbps over 100 meters (or up to 10 Gbps over shorter distances).
Key Features
- Category 6 (Cat 6) cable is a twisted pair Ethernet cable used for networking and data transfer. It is backward compatible with Cat 5 and Cat 5e but offers improved performance and bandwidth, supporting frequencies up to 250 MHz and data transfer rates up to 1 Gbps over 100 meters (or up to 10 Gbps over shorter distances).
- Conductor: 23 AWG solid bare copper (or CCA optional)
- Shielding: UTP (Unshielded Twisted Pair) / STP / FTP options available
- Jacket: PVC / LSZH (Low Smoke Zero Halogen) / PE (for outdoor)
- Frequency Bandwidth: Up to 250 MHz
- Data Rate Support: 10/100/1000 Mbps (up to 10 Gbps for ≤55m)
- Cable Type: 4 twisted pairs with a central spline for crosstalk reduction
- Compliance: ANSI/TIA-568-C.2, ISO/IEC 11801, RoHS
- Flame Retardant: Meets IEC 60332-1 and CM/CMR fire ratings
- Color Options: Blue, Grey, Yellow, Red, Black, and Custom Colors
Global Presence
- Presence across major sectors, brands, and countries.
- Transparency in all dealings.
- World class manufacturing facilities.
- Robust R&D Capabilities.
- End-to-end solutions provider.
- Visionary promoters & management.
Why Choose Us
- High-Speed Data Transmission – Reliable up to 1 Gbps for 100m runs
- Enhanced Crosstalk Performance – Reduces noise and signal degradation
- Backward Compatibility – Works with Cat 5/5e standards and equipment
- Flexible Installation – Suitable for patch cables, structured cabling, and more
- Multiple Jacket Options – Choose between indoor, outdoor, and LSZH safety variants
- Scalable for Future – Supports 10G Ethernet in short-distance applications
Applications
- Home and office Ethernet networking
- Enterprise LAN installations
- Wi-Fi access point backhaul
- CCTV IP surveillance systems
- Data centers and server racks
- PoE (Power over Ethernet) enabled devices
- Smart home automation & IoT integration
| Parameter | Specification |
|---|---|
| Conductor Material | Solid bare copper (23 AWG) or Copper-Clad Aluminum |
| Cable Construction | 4 twisted pairs with spline separator (Cat 6) |
| Shielding Options | UTP / STP / FTP |
| Outer Jacket | PVC / LSZH / PE |
| Bandwidth | Up to 250 MHz |
| Data Rate | 1 Gbps (up to 100m), 10 Gbps (up to 55m) |
| Flame Rating | CM / CMR / CMP / IEC 60332-1 |
| Voltage Rating | 300V |
| Temperature Range | -20°C to +60°C (operating) |
| Certification | UL Listed, RoHS, ISO/IEC 11801, ANSI/TIA-568-C.2 |
| Packaging | 305m pull box / drum / custom lengths available |
