Unilay HRFR Cables

Unilay HRFR Cables

Overview

Unilay HRFR Cables combine the benefits of advanced conductor construction and flame-retardant insulation. The Unilay process involves compactly bunching equal-size strands together in a concentric layer for a smoother conductor profile, uniform current flow, and easier handling. These cables are insulated with Heat Resistant Flame Retardant (HRFR) PVC, offering excellent thermal stability and flame resistance.

Key Features

  • Conductor: 99.97% pure annealed copper using Unilay construction
  • Insulation: Specially formulated HRFR PVC compound
  • Voltage Grade: 1100 Volts
  • Temperature Range: -15°C to +85°C
  • Conductor Type: Class 2 (Unilay compact stranded)
  • Outer Diameter: Uniform and compact for smooth installation
  • Color Options: Red, Yellow, Blue, Green, Black, Grey, and more
  • Available Sizes: 0.5 sq.mm to 16 sq.mm (Custom sizes on request)
  • Flame Retardancy: Conforms to IS 10810 & IEC 60332-1
  • Environmental Compliance: Lead-free, RoHS compliant

Global Presence

  • Presence across major sectors, brands, and countries.
  • Transparency in all dealings.
  • World class manufacturing facilities.
  • Robust R&D Capabilities.
  • End-to-end solutions provider.
  • Visionary promoters & management.

Why Choose Us

  • Smooth & Compact: Easier cable pulling through conduits
  • High Safety: Flame-retardant insulation slows down fire spread
  • Thermal Endurance: Performs under heat without melting or deformation
  • Lower Power Losses: Uniform current distribution with minimal resistance
  • Durable & Long-Lasting: Resists oil, chemicals, moisture, and abrasion
  • Trusted Compliance: IS 694:2010, RoHS, CE Certified

Applications

  • Internal wiring in residential & commercial buildings
  • Control panels and electrical boards
  • Power and lighting circuits
  • Industrial automation wiring
  • False ceilings, ducting, and concealed wiring
Parameter Specification
Conductor 99.97% Electrolytic Grade Copper (Unilay)
Insulation Material HRFR PVC Compound
Voltage Rating 1100 Volts AC
Operating Temperature -15°C to +85°C
Insulation Resistance > 1 Mega Ohm/km at 27°C
Flame Retardant Standard IS 10810, IEC 60332-1
Cable Sizes Available 0.5 sq.mm to 16 sq.mm
Packaging 90m / 100m Coils or Custom Reels
